Share Beam Load Cell IN-3411

Product Categories

Innovation Electronic Co.,Ltd

Contact Now

Name: Share Beam Load Cell IN3411
Brand: Innovation
Price: 1 USD

Add to Cart

single beam load cell IN-3411

Interchangeable Products

Vishay-Tedea 3400 load cell

Items	UNIT	TECHNICAL DATA

Capacity	t	0.05-10

Rated output	mV/V	3.0±0.04

Accuracy class		C2	C3

Combined error	%RO	<±0.030	<±0.020

Zero balance	%RO	±1.0

Input resistance	Ω	380±10	1050±10

Output resistance	Ω	350±3	1000±5

Insulation resistance	MΩ(50V)	5000

Recommended excitation voltage	V	5~12

Compensated temperature range	ºC	-10~+40

Operating temperature range	ºC	-35~+80

Safe overload	%RO	150

Ultimate overload	%RO	200

Load cell material		Alloy steel IP67

		17-4PH	Stainless steel IP68

Connecting cable		0.25~3tφ5.7X3.5m

		5~10tφ5.7X6m

Method of connecting wire		RedEX(+) Black(EX-) Green(Sig+)White(Sig-)
